Pulse Input Module SPI012
SPI012 module specifications
Item Specification
Model name SPI012
Number of input points 4 points
Input insulation unit The 4 points are isolated together
Input signal (Note 1) Non-voltage contact (open collector input)/Each voltage pulse
point can be set independently
Counter 16 bit up counter
Input current (Non-voltage contact) 7 mA (24 Vdc)
Input resistance (Voltage pulse)
With power ON/power OFF: 10 k
MIN.
Input frequency Non-voltage contact: DC-50Hz
Voltage pulse: DC-10kHz
Rated input voltage Non-voltage contact:
ON Potential between external supply voltage (+) and PI (+)
18 V
OFF Potential between external supply voltage (+) and PI (+)
4 V
Voltage pulse: 2-30 V
P-P
DC bias for voltage pulse 1-13 Vdc
Minimum pulse width Non-voltage contact: 10 ms (ON/OFF)
Voltage pulse: 50
s (ON/OFF)
Address setting Set from 1 to E (decimal 1 to 14) by front panel address setting
switch.
Pulse threshold voltage setting (Note
2)
1 to 14V; in terms of 1V as a unit; setup accuracy:
(set value's
6% + 0.3V)
Breakdown diagnosis External power supply voltage drop, transmission, CPU, memory,
Basic pulse
Insulation resistance
100 M
or more (measured with 500 Vdc megger, between total
inputs and internal circuits)
Ability of insulation to withstand voltage
500 Vac for 1 minute (between total inputs and internal circuits)
External power supply
24 Vdc
10% (21.6 to 26.4V), ripple 5% or less.
External power supply current
consumption
24 Vdc-50 mA or less
Current consumption 24 Vdc-150 mA or less (system power supply)
Internal heat generation 4.8 W or less (external 24 Vdc, all points input)
Compatible terminal block units UTBA1
Compatible options
-
Applicable I/O base unit UABU1
External dimensions
40 W
90 H
95 D mm (excluding protrusions)
Weight 150 g or less
(Note 1) The setting (non-voltage/voltage, instantaneous unit time) of each channel should be performed
using the engineering tool. For the setting method, see
“
Chapter 7 Registering MCS
Configuration
”
of the
“
Engineering Tool Instruction Manual
”
(6F8C0696).
(Note 2) The pulse width must be at least
1 V for the pulse threshold set voltage.
