3.
System Configuration Unit and Module
112
Pulse Output Module SPO01
SPO01 module specifications
Item Specification
Model name SPO01
Number of output points 4 points
Output insulation unit The 4 points are isolated together
Output signal Open collector output
Resolution 8 bit
Output type Pulse width: Select either 72 or 9 ms (same setting for all points).
Pulse train: Select either 28 or 111 Hz (same setting for all points).
Pulse direction Open or close derection
Output applied voltage 13.5 - 26.4 Vdc
Output current Resistance load: 100 mA/point (Max.)
Inductive load: 50 mA/point (Max.)
Leak current when output
is OFF
100
A or less
Voltage drop when output
is ON
1 V or less (Resistance load: 100 mA)
Risetime
20
s/10 - 90% or less (Resistance load: 100 mA)
Address setting Set from 1 to E (decimal 1 to 14) by front panel address setting switch.
Breakdown diagnosis External power supply voltage drop, transmission, CPU, memory,
Read-back check.
Insulation resistance
100 M
or more (measured with 500 Vdc megger, between total
outputs and internal circuits)
Ability of insulation to
withstand voltage
500 Vac for 1 minute (between total outputs and internal circuits)
External power supply
24 Vdc
10% (21.6 to 26.4V), ripple 5% or less.
External power supply
current comsumption
24 Vdc-15 mA or less
Current consumption 24 Vdc-100 mA or less (system power supply)
Internal heat generation 2.7 W or less (external 24 Vdc, all points output)
Compatible terminal block
units
UTBA1
Compatible options
-
Compatible terminal block
units
UABU1
External dimensions
40 W
90 H
95 D mm (excluding protrusions)
Weight 150 g or less
(Note 1) The setting by output type should be performed using the engineering tool. For the setting method,
see
“
Chapter 7 Registering MCS Configuration
”
of the
“
Engineering Tool Instruction Manual
”
(6F8C0696).
