Toshiba TOSDIC-CIE DS User Manual

1. System Configuration
4
Communication
base unit
2 SBIF1s are
mounted.
PI/O modules
(maximum 14)
I/O bus; power supply
capacity within 2.2 A
Maximum 15
Termination
connector
I/O bus cable
Serial bus cables With termination resistors
(Note) The serial bus, I/O bus and communication modules are all dual.
Control station PCS-DS
With termination resistors
Figure 1.2 Standard system expansion configuration
