Toshiba TOSDIC-CIE DS User Manual

3. System Configuration Unit and Module
76
SAI03 module external wiring
 When UTBA2 is mounted
GND
4-20 mAdc 2-wire
type sensor
(TB1/TB2)
250 
SAI03
(FIVC11, FIVC12)
FG
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
FG
AI1(+)
AI1( - )
AI2(+)
AI2( - )
AI3(+)
AI3( - )
AI4(+)
AI4( - )
-
+
-
+
-
+
-
+
DP1
DP2
DP3
DP4
SAI03 front panel
RUN indicator:
Lights up during
normal operation.
Alarm indicator:
Blinks in an abnormal
operation.
Module address setting switch:
Sets address numbers 1 to E
(decimal 1 to 14).
AI03
1-5V dc DIS
TOSHIBA
RUN
ALM
ADDR
4
C
3
B
2
A
1
9
0
8
F
7
E
6
D
5
CH1
CH4
CH3
CH2
OFF ON
Sensor power supply switches
(CH1 to CH4)
