Toshiba TOSVERT-130 G3 - Group:protection Function Parameters

37
9.3.7 GROUP:PROTECTION FUNCTION PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
11F DYNAMIC BRAKING
SELECTION
0 / 1 0003 0000: no dynamic braking (0)
0001: with dynamic braking, no DBR
overload trip (1)
0003: with dynamic braking and
DBR overload trip (2)

120 2 BRAKING RESISTOR
VALUE
0 / 1 FFFF 000A ∼ 2710 (1.0 ∼ 1000) 0.1
121 BRAKING RESISTOR
POWER RATING
0 / 1 FFFF 0001 ∼ EA60 (0.01 ∼ 600.00) 0.01
122 OVERVOLTAGE STALL
PROTECTION
0 / 1 0004 0000: ON (0)
0004: OFF (1)

123 DC INJECTION START
FREQUENCY
0 / 1 FFFF 0000 ∼ 2EE0 (0.00 ∼ 120.00) 0.01
124 Other
than 0
DC INJECTION
CURRENT
MAGNITUDE
0 / 1 00FF 0000 ∼ 0064 (0 ∼ 100) 1
125 DC INJECTION
TIME
0 / 1 00FF 0000 ∼ 0064 (0.0 ∼ 10.0) 0.1
126 FWD/REV DC INJECT
PRIORITY CTRL
0 / 1 0040 0000: OFF (0)
0040: ON (1)

127 MOTOR SHAFT
STATIONARY CTRL
0 / 1 0080 0000: OFF (0)
0080: ON (1)

128 EMERGENCY OFF MODE
SELECTION
0 / 1 0030 0000: Coast stop (0)
0010: Decelerated stop (1)
0020: DC injection stop (2)

129 2 EMERGENCY OFF DC
INJECTION TIME
0 / 1 00FF 0000 ∼ 0064 (0.0 ∼ 10.0) 0.1
12A NUMBER OF RETRY
ATTEMPTS
0 / 1 00FF 0000 ∼ 000A (0 ∼ 10) 1
12B Other
than 0
TIME BETWEEN
RETRY
ATTEMPTS
0 / 1 00FF 0000 ∼ 0064 (0.0 ∼ 10.0) 0.1
12C REGENERATION POWER
RIDE-THROUGH
0 / 1 0008 0000: OFF (0)
0008: ON (1)

12D 1 REGEN RIDE-
THROUGH TIME
0 / 1 00FF 0000 ∼ 00FA (0.0 ∼ 25.0) 0.1
12E AUTO-RESTART (MOTOR
SPEED SEARCH)
0 / 1 0018 0000: OFF (0)
0008: On power failure (1)
0010: On ST make/break (2)
0018: Both (1) and (2) (3)

12F ELECTRONIC THERMAL
PROTECT LVL #1
0 / 1 00FF 000A ∼ 0064 (10 ∼ 100) 1
130 OVERLOAD REDUCTION
START FREQ
0 / 1 FFFF 0000 ∼ 0BB8 (0.00 ∼ 30.00) 0.01
131 MOTOR 150% OVERLOAD
TIME LIMIT
0 / 1 00FF 0001 ∼ 00F0 (10 ∼ 2400) 10
132 OVERLOAD SELECTION 0 / 1 0030 0000: with motor overload trip,
without soft-stall (0)
0010: with motor overload trip and
soft-stall (1)
0020: without soft-stall or motor
overload trip (2)
0030: with soft-stall, without motor
overload trip (3)

133 STALL PROTECTION
ENABLE
0 / 1 0040 0000: ON (0)
0040: OFF (1)

134 0 STALL PROTECTION
CURRENT LEVEL
0 / 1 00FF 000A ∼ 00D7 (10 ∼ 215) 1
