9.4 Write-Only Coils
The following write-only “0X” coils are available via the Modbus command 05. These
coils access the same bits which are detailed in holding register 02 (refer to section
9.1 of this manual).
Coil Function Bank Function
01 RUN command DPRAM OFF: Stop
ON: Run
02 STOP Command (has priority over RUN
command)
OFF: Run enabled
ON: Stop
03 Forward • reverse run selection OFF: Reverse
ON: Forward
04 Acc/dec #1 / #2 selection OFF: Acc / dec #1
ON: Acc / dec #2
05 Jog mode selection OFF: Normal (acc/dec mode)
ON: Jog mode
06 Feedback control OFF: Feedback valid
ON: Feedback invalid
07 Compulsory DC injection braking mode OFF: No compulsory DC injection braking
ON: Compulsory DC injection below DC
INJECTION START FREQUENCY
08 Fundamental parameter switching OFF: V/F #1
ON: V/F #2
09 Gate block command (coast stop
command)
OFF: Normal
ON: Gate block
0A Emergency off command OFF: Does nothing
ON: Emergency off
0B Reset command (trip clear) OFF: Does nothing
ON: Reset
0C Reserved
0D Reserved
0E Reserved
0F Reserved
10 Reserved
