9.5 Read-Only Coils
The following read-only “0X” coils are available via Modbus command 01. These coils
access the same bits which are detailed in holding register 06 (refer to section 9.2 of
this manual).
Coil Function Bank Function
11 Run • stop status DPRAM OFF: Stopped
ON: Running
12 Run enable status OFF: Run enabled
ON: Stopped
13 Forward • reverse status OFF: Reverse
ON: Forward
14 Acc / dec #1 / #2 selection status OFF: Acc / dec #1
ON: Acc / dec #2
15 Fault status OFF: Faulted
ON: Not faulted
16 Jog mode status OFF: Normal (acc/dec mode)
ON: Jog mode
17 Feedback enable status OFF: Feedback valid
ON: Feedback invalid
18 Compulsory DC injection braking mode
status
OFF: DC injection braking inactive
ON: DC injection braking active
19 Fundamental parameter switching status OFF: V/F #1
ON: V/F #2
1A Coast stop command status OFF: Normal
ON: Coasting to stop
1B Emergency off command status OFF: Normal
ON: Emergency off
1C Main circuit undervoltage (MSV) status OFF: Normal
ON: MSV
1D Reserved 
1E Reserved 
1F Reserved 
20 Reserved 
