9.3.8 GROUP:PATTERN RUN CONTROL PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
146 PATTERN RUN
SELECTION
0 / 1 0008 0000: OFF (0)
0008: ON (1)

147 1
PATTERN RUN
CONTINUE MODE
0 / 1 0001 0000: reset on stop (0)
0001: switch when done (1)

148 PATTERN GROUP #1
SPEED #0
1 00FF 0000: Skip (0) 1
149 PATTERN GROUP #1
SPEED #1
0001 ∼ 000F: Speeds 1 ∼ 15
150 PATTERN GROUP #1
SPEED #2
151 PATTERN GROUP #1
SPEED #3
152 PATTERN GROUP #1
SPEED #4
153 PATTERN GROUP #1
SPEED #5
154 PATTERN GROUP #1
SPEED #6
155 PATTERN GROUP #1
SPEED #7
156 PATTERN GROUP #1
NUMBER OF CYCLES
0 / 1 00FF 0001 ∼ 00FF: 1 ∼ 255 1
157 PATTERN GROUP #2
SPEED #0
1 00FF 0000: Skip (0) 1
158 PATTERN GROUP #2
SPEED #1
0001 ∼ 000F: Speeds 1 ∼ 15
159 PATTERN GROUP #2
SPEED #2
15A PATTERN GROUP #2
SPEED #3
15B PATTERN GROUP #2
SPEED #4
15C PATTERN GROUP #2
SPEED #5
15D PATTERN GROUP #2
SPEED #6
15E PATTERN GROUP #2
SPEED #7
15F PATTERN GROUP #2
NUMBER OF CYCLES
0 / 1 00FF 0001 ∼ 00FF: 1 ∼ 255 1
160 PATTERN GROUP #3
SPEED #0
1 00FF 0000: Skip (0) 1
161 PATTERN GROUP #3
SPEED #1
0001 ∼ 000F: Speeds 1 ∼ 15
162 PATTERN GROUP #3
SPEED #2
163 PATTERN GROUP #3
SPEED #3
164 PATTERN GROUP #3
SPEED #4
165 PATTERN GROUP #3
SPEED #5
166 PATTERN GROUP #3
SPEED #6
167 PATTERN GROUP #3
SPEED #7
168 PATTERN GROUP #3
NUMBER OF CYCLES
0 / 1 00FF 0001 ∼ 00FF: 1 ∼ 255 1
