9.3.4 GROUP:TERMINAL SELECTION PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
44 INPUT TERMINAL
SELECTION
0 / 1 0001 0000: Standard functions (0)
0001: Individual selections (1)

45 1 “R” INPUT
TERMINAL FUNCTION
0 / 1 FFFF 0000 ∼ FFFF (0 ∼ 54) 
46 “S1” INPUT
TERMINAL FUNCTION
Refer to Table 5 (page 31)
47 “S2” INPUT
TERMINAL FUNCTION
48 “S3” INPUT
TERMINAL FUNCTION
49 “S4” INPUT
TERMINAL FUNCTION
4A “F” INPUT
TERMINAL FUNCTION
4B “RES” INPUT
TERMINAL FUNCTION
4C “ST” INPUT
TERMINAL FUNCTION
4D “S5” INPUT
TERMINAL FUNCTION
4E “S6” INPUT
TERMINAL FUNCTION
4F “S7” INPUT
TERMINAL FUNCTION
50 POTENTIAL
TERMINAL FUNCTION
51 R,S1-S7 TERMINAL
RESPONSE TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
52 F INPUT TERMINAL
RESPONSE TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
53 RES INPUT TERMINAL
RESPONSE TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
54 ST INPUT TERMINAL
RESPONSE TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
55
“RCH” CONTACTS
FUNCTION
0 / 1 FFFF 0 ∼ FFFF (0 ∼ 63)
Refer to Table 6 (page 32)

56
“RCH” CONTACTS DELAY
TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
57
“RCH” CONTACTS HOLD
TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
58
“LOW” CONTACTS
FUNCTION
0 / 1 FFFF 0 ∼ FFFF (0 ∼ 63)
Refer to Table 6 (page 32)

59
“LOW” CONTACTS DELAY
TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
5A
“LOW” CONTACTS HOLD
TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
5B
“FL” CONTACTS
FUNCTION
0 / 1 FFFF 0 ∼ FFFF (0 ∼ 63)
Refer to Table 6 (page 32)

5C
“FL” CONTACTS DELAY
TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
5D
“FL” CONTACTS HOLD
TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
5E
“OUT” CONTACTS
FUNCTION
0 / 1 FFFF 0 ∼ FFFF (0 ∼ 63)
Refer to Table 6 (page 32)

5F
“OUT” CONTACTS DELAY
TIME
0 / 1 00FF 0001 ∼ 0064 (1 ∼ 100) 1
