9.3.13 GROUP:MOTOR RATING PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
242 NUMBER OF MOTOR
POLES
0 / 1 00FF 0001: (2)
0002: (4)
0003: (6)
0004: (8)
0005: (10)
0006: (12)
0007: (14)
0008: (16)
2
243 MOTOR RATED
CAPACITY
0 / 1 FFFF 0001 ∼ 270F (0.1 ∼ 999.9) 0.1
244 MOTOR TYPE 0 / 1 0030 0000:Toshiba EQPIII motor (0)
0010:Toshiba STD motor (1)
0020:Other (2)

245 2 MOTOR RATED
VOLTAGE
(230 / 460v units)
0 / 1 00FF 0012 ∼ 0078 (90 ∼ 600) 5
246 (575v units) 001A ∼ 00AC (130 ∼ 860)
247 MOTOR RATED
FREQUENCY
0 / 1 00FF 0000 ∼ 00C8 (0 ∼ 400) 2
248 MOTOR RATED RPM 0 / 1 FFFF 0000 ∼ 270F (0 ∼ 9999) 1
249 AUTO-TUNING
ENABLE
0 0008 0000: Auto-tuning disabled (0)
0008: Auto-tuning enabled (1)

24A LOAD MOMENT OF
INERTIA
0 / 1 00C0 0000: Small (0)
0040: Medium (1)
0080: Large (2)
00C0: Very large (3)

9.3.14 Programmable Pointer Registers
Register Function / Title Bank Mask Adjustment Range Multiplier
24B ∼
26A
Programmable Address
Registers (32 total)
0 FFFF 1 ∼ 24A 
26B ∼
28A
Programmable Data
Registers (32 total)
According to the attributes of the registers programmed in 24B∼26A
