9.3.10 GROUP:COMMUNICATION SETTING PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
1D0 Loss of communications
timeout time
1 100 ∼ 60000 (0.100s ∼ 60.000s) 0.001
1D1 Loss of communications
timeout action
1 0 ∼ 4
1D2 Response delay time 1 0 ∼ 2000 (0s ∼ 2.000s) 0.001
1D3 ∼ 200
Reserved
201 RS232 BAUD RATE 1 0018 0000: 2400 baud (0)
0008: 4800 baud (1)
0010: 9600 baud (2)
202 NUMBER OF DATA BITS 1 0040 0000: 7 bits (0)
0040: 8 bits (1)
.203 PARITY SETTING 1 0080 0000: Even parity (0)
0080: Odd parity (1)
204 INVERTER ID NUMBER 1 00FF 0000 ∼ 00FF (0 ∼ 255) 1
205 COMMUNICATION
SELECTION
1 0007 0000: OFF (0)
0001: RS485 (1)
0002: Modbus, F10, DeviceNet (2)
0003: TOSLINE S-20 (3)
0004: 12 bit binary input (4)
0005: 3-digit BCD (0.1Hz) (5)
0006: 3-digit BCD (1Hz) (6)
206 1 MASTER/SLAVE
SELECTION
1 0018 0000: Slave (0)
0008: Master (frequency command)
(1)
0010: Master (output frequency)(2)
207 RS485 BAUD RATE 1 0004 0000: Normal mode (0)
0004: High-speed mode (1)
208 2 TOSLINE-F10
COMMAND INPUT
1 0003 0000: OFF (0)
0001: Frequency command (1)
0002: Command input (2)
0003: Both (1) and (2) (3)
209 TOSLINE-F10
MONITOR OUTPUT
1 003C 0000: (0) 0020: (8)
0004: (1) 0024: (9)
0008: (2) 0028: (10)
000C: (3) 002C: (11)
0010: (4) 0030: (12)
0014: (5) 0034: (13)
0018: (6) 0038: (14)
001C: (7) 003C: (15 )
20A TOSLINE-F10 COMM
ERROR MODE
1 0080 0000: Data cleared (0)
0080: Data retained (1)
20B 3 TOSLINE-S20
RECEIVE ADDRESS
1 FFFF 0000 ∼ 03FF (0 ∼ 1023) 1
20C TOSLINE-S20
TRANSMIT ADDRESS
1 FFFF 0000 ∼ 03FF (0 ∼ 1023) 1
20D TOSLINE-S20
COMMAND INPUT
1 001F 0000 ∼ 001F (0 ∼ 31) 1
20E TOSLINE-S20
MONITOR OUTPUT
1 001F 0000 ∼ 001F (0 ∼ 31) 1
20F TOSLINE-S20 FREQ
REF ADDR SELECT
1 0001 0000: Disable (0)
0001: Enable (1)
1
210 1 TOSLINE-S20
FREQ REF
ADDR
1 FFFF 0000 ∼ 03FF (0 ∼ 1023) 1
