9.3.5 GROUP:SPECIAL CONTROL PARAMETERS
Register Function / Title Bank Mask Adjustment Range Multiplier
69 START-UP FREQUENCY 0 / 1 FFFF 0000 ∼ 03E8 (0.00 ∼ 10.00) 0.01
6A ∼ 6F Reserved    
70 END FREQUENCY 0 / 1 FFFF 0000 ∼ 0BB8 (0.00 ∼ 30.00) 0.01
71 RUN FREQUENCY 0 / 1 FFFF 0000 ∼ Fmax 0.01
72 RUN FREQUENCY
HYSTERESIS
0 / 1 FFFF 0000 ∼ 0BB8 (0.00 ∼ 30.00) 0.01
73 ENABLE JUMP
FREQUENCIES
0 / 1 0080 0000: Function OFF (0)
0080: Function ON (1)

74 1 JUMP FREQUENCY
#1
0 / 1 FFFF 0000 ∼ Fmax 0.01
75 JUMP FREQUENCY
#1 BANDWIDTH
0 / 1 FFFF 0000 ∼ 0BB8 (0.00 ∼ 30.00) 0.01
76 JUMP FREQUENCY
#2
0 / 1 FFFF 0000 ∼ Fmax 0.01
77 JUMP FREQUENCY
#2 BANDWIDTH
0 / 1 FFFF 0000 ∼ 0BB8 (0.00 ∼ 30.00) 0.01
78 JUMP FREQUENCY
#3
0 / 1 FFFF 0000 ∼ Fmax 0.01
79 JUMP FREQUENCY
#3 BANDWIDTH
0 / 1 FFFF 0000 ∼ 0BB8 (0.00 ∼ 30.00) 0.01
7A ∼ 7F Reserved    
80 PWM CARRIER
FREQUENCY (Note 1)
0 / 1 00FF 0005 ∼ 0064 (0.5 ∼ 10.0) 0.1
Note 1: Actual adjustment range depends on inverter rating.
