32
Table 6: Output Terminal Selections (RCH, LOW, FL, OUT relay contacts)
Setting
Value
Data
(Hex)
Function Setting
Value
Data
(Hex)
Function
0 0000 Lower limit frequency 32 C5B7 Executing emergency off
1 0100 /Lower limit frequency 33 CDB7 /Executing emergency off
2 0200 Upper limit frequency 34 B5BB Executing retry
3 0300 /Upper limit frequency 35 BDBB /Executing retry
4 0400 Low speed signal 36 D5CF Pattern run switching output
5 0500 /Low speed signal 37 DDCF /Pattern run switching output
6 0600 Accel/decel complete 38 D5D8 PID deviation limit
7 0700 /Accel/decel complete 39 DDD8 /PID deviation limit
8 0800 Selected speed reach signal 40 C5BB Run/stop
9 0900 /Selected speed reach signal 41 CDBB /Run/stop
10 0A00 Fault 42 1400 Severe fault (armature short, load-
end short, open phase, output
error, earth fault)
11 0B00 /Fault 43 1500 /Severe fault (armature short,
load-end short, open phase,
output error, earth fault)
12 0C00 Fault other than earth fault or
load-end overcurrent
44 1600 Non-severe fault (overload,
overcurrent, overvoltage)
13 0D00 /Fault other than earth fault or
load-end overcurrent
45 1700 /Non-severe fault (overload,
overcurrent, overvoltage)
14 95B5 Overcurrent pre-alarm 46 E5D8 Commercial power / inverter
sw itching output #1
15 9DB5 /Overcurrent pre-alarm 47 EDD8 /Commercial power / inverter
switching output #1
16 85C5 Inverter overload pre-alarm 48 F5D8 Commercial power / inverter
switching output #2
17 8DC5 /Inverter overload pre-alarm 49 FDD8 /Commercial power / inverter
switching output #2
18 95C5 Motor overload pre-alarm 50 85C0 Fan ON/OFF
19 9DC5 /Motor overload pre-alarm 51 8DC0 /Fan ON/OFF
20 D5C5 Overheat pre-alarm 52 F5B6 Executing JOG
21 DDC5 /Overheat pre-alarm 53 FDB6 /Executing JOG
22 A5B4 Overvoltage pre-alarm 54 1800 Local/remote operation
23 ADB4 /Overvoltage pre-alarm 55 1900 /Local/remote operation
24 E5B4 Undervoltage alarm 56 A5D1 Cumulative timer alarm
25 EDB4 /Undervoltage alarm 57 ADD1 /Cumulative timer alarm
26 85B5 Undercurrent alarm 58 1A00 Communication error alarm
27 8DB5 /Undercurrent alarm 59 1B00 /Communication error alarm
28 85D1 Overtorque alarm 60 A5B6 F/R
29 8DD1 /Overtorque alarm 61 ADB6 /F/R
30 E5BB Braking resistor OL pre-alarm 62 1E00 Run preparation complete
31 EDBB /Braking resistor OL pre-alarm 63 1F00 /Run preparation complete
