Register Function / Title Bank Mask Adjustment Range Multiplier
169 PATTERN GROUP #4
SPEED #0
1 00FF 0000: Skip (0) 1
16A PATTERN GROUP #4
SPEED #1
0001 ∼ 000F: Speeds 1 ∼ 15
16B PATTERN GROUP #4
SPEED #2
16C PATTERN GROUP #4
SPEED #3
16D PATTERN GROUP #4
SPEED #4
16E PATTERN GROUP #4
SPEED #5
16F PATTERN GROUP #4
SPEED #6
170 PATTERN GROUP #4
SPEED #7
171 PATTERN GROUP #4
NUMBER OF CYCLES
0 / 1 00FF 0001 ∼ 00FF: 1 ∼ 255 1
172 SPEED #1 CONTINUE
MODE
1 00FF 0000: Count in seconds from time of
activation (0)
0001: Count in minutes from time of
activation (1)
0002: Count in seconds from speed
reach (2)
0003: Count in minutes from speed
reach (3)
0004: Non-stop (continue until STOP
command) (4)
0005: Continue until next step
command (5)

173 < 4
SPEED #1
DRIVE TIME
1 FFFF 0000 ∼ 1F40 (0 ∼ 8000) 1
174 SPEED #2 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

175 < 4
SPEED #2
DRIVE TIME
1 FFFF 0000 ∼ 1F40 (0 ∼ 8000) 1
176 SPEED #3 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

177 < 4
SPEED #3
DRIVE TIME
1 FFFF 0000 ∼ 1F40 (0 ∼ 8000) 1
178 SPEED #4 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

179 < 4
SPEED #4
DRIVE TIME
1 FFFF 0000 ∼ 1F40 (0 ∼ 8000) 1
17A SPEED #5 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

17B < 4
SPEED #5
DRIVE TIME
1 FFFF 0000 ∼ 1F40 (0 ∼ 8000) 1
17C SPEED #6 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

17D < 4
SPEED #6
DRIVE TIME
1 FFFF 0000 ∼ 1F40 (0 ∼ 8000) 1
17E SPEED #7 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

17F < 4
SPEED #7
DRIVE TIME
1 FFFF 0000 ∼ 1F40 (0 ∼ 8000) 1
180 SPEED #8 CONTINUE
MODE
1 00FF Same as SPEED #1 CONTINUE
MODE

181 < 4
SPEED #8
DRIVE TIME
1 FFFF 0000 ∼ 1F40 (0 ∼ 8000) 1
