Toshiba TOSVERT VF-PS1 User Manual

K-16
E6581386
11
[20] Adjustment parameters Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Constant Reference
 0458 Current control proportional gain 0~1000 1/1 0 Disabled ●/● - - *1
 0460 Speed loop proportional gain 1~9999 1/1 12 Enabled ●/● - - *1
 0461 Speed loop stabilization coefficient 1~9999 1/1 100 Enabled ●/● - - *1
 0462 Moment of inertia of load 1 0~100 1/1 35 Enabled ●/● ● - *1
 0467 Motor oscillation control
0:Disabled
1:Enabled(Low gain)
2:Enabled(Middle gain)
3:Enabled(High gain)
1/1 0 Disabled -/- - ● 6.22.2
 0468 Stall prevention control switching
0: Stall prevention control 1
1: Stall prevention control 2
1/1 0 Disabled -/- - ● 6.22.3
 0469 Overvoltage limit constant 0: Automatic, 1~1000ms 1/1 0 Disabled -/- - ● 6.15.2
 0470 VI/II input bias 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0471 VI/II input gain 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0472 RR/S4 input bias 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0473 RR/S4 input gain 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0474 RX input bias 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0475 RX input gain 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0476 Optional AI1 input bias 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0477 Optional AI1 input gain 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0478 Optional AI2 input bias 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0479 Optional AI2 input gain 0~255 1/1 *2 Enabled ●/● ● ● 6. 23
 0495 Max output voltage modulation rate
0:Standard
1:Straight 100%
2:102.5%
3:105%
1/1 0 Disabled ●/● ● ● 6.22.4
 0498 PM motor constant 1 (d axis inductance) 0~25% 0.1/0.1 10.0 Disabled - ● - 6. 24
 0499 PM motor constant 2 (q axis inductance) 0~25% 0.1/0.1 10.0 Disabled - ● - 6. 24
*1:  For details, refer to Instruction Manual (E6581333) specified in Section 6.36. *2:  Settings vary from unit to unit. Even if  is set to , no change is made to these values.
[21] Acceleration/deceleration 2 Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Constant Reference
 0500 Acceleration time 2 0.1~6000 sec. 0.1/0.1 *2 *1 Enabled ●/● ● ● 6. 25. 1
 0501 Deceleration time 2 0.1~6000 sec. 0.1/0.1 *2 *1 Enabled ●/● ● ● 6. 25. 1
 0502 Acceleration/deceleration 1 pattern
0:Straight
1:S-pattern 1
2:S-pattern 2
1/1 0 Enabled ●/● ● ● 6. 25. 1
 0503 Acceleration/deceleration 2 pattern
0:Straight
1:S-pattern 1
2:S-pattern 2
1/1 0 Enabled ●/● ● ● 6. 25. 1
 0504 Panel acceleration/deceleration selection
1:Acceleration/deceleration 1
2:Acceleration/deceleration 2
1/1 １ Enabled ●/● ● ● 6. 25. 1
 0505
Acceleration/deceleration switching
frequency
0.0~ Hz 0. 1/0.01 0.0 Enabled ●/● ● ● 6. 25. 1
*1: Default values vary depending on the capacity.  See the table of K-42. *2: Changing the parameter  enables to set to 0.01 sec. (adjustment range: 0.01~600.0 sec.).
