K-21
E6581386
11
[25] Meter output Sensorless vector/PG feedback control (:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Constant
Reference
 0671 AM terminal meter adjustment - 1/1 - Enabled / 5. 16
 0672 MON1 terminal meter selection 0~76 *1 1/1 4 Enabled / *2
 0673 MON1 terminal meter adjustment - 1/1 - Enabled / *2
 0674 MON2 terminal meter selection 0~76 *1 1/1 5 Enabled / *2
 0675 MON2 terminal meter adjustment - 1/1 - Enabled / *2
 0676 Pulse output function selection 0~49 *1 1/1 0 Enabled / 6. 30. 1
 0677 Selection of number of pulses 1.00~43.20kHz 0.01/0.01 3.84 Enabled / 6. 30. 1
 0678 Constant at the time of filtering 4msec, 8msec~100msec 1/1 64 Enabled / 5. 16
 0681 FM voltage/current output switching
0:Voltage 0~10V output
1:Current 0~20mA output
1/1 0 Disabled / 6. 30. 3
 0682 FM output gradient characteristic
0:Negative gradient (descending)
1:Positive gradient (ascending)
1/1 1 Enabled / 6. 30. 3
 0683 FM bias adjustment -10.0~100.0% 0.1/0.1 0.0 Enabled / 6. 30. 3
 0684 FM output filter
0:No filter
1:Filter approx. 10ms
2:Filter approx. 15ms
3:Filter approx. 30ms
4:Filter approx. 60ms
5:Filter approx. 120ms
6:Filter approx. 250ms
7:Filter approx. 500ms
8:Filter approx. 1s
1/1 0 Enabled / 5. 16
 0685 AM output gradient characteristic
0:Negative inclination (downward slope)
1:Positive inclination (upward slope)
1/1 1 Enabled / 6. 30. 3
 0686 AM bias adjustment -10.0~100.0% 0.1/0.1 0.0 Enabled / 6. 30. 3
 0688 MON1 voltage/current output switching
0:Voltage -10~10V output
1:Voltage 0~10V output
2:Current 0~20mA output
1/1 1 Disabled / *2
 0689 MON1 output gradient characteristic
0:Negative inclination (downward slope)
1:Positive inclination (upward slope)
1/1 1 Enabled / *2
 0690 MON1 bias adjustment -10.0~100.0% 0.1/0.1 0.0 Enabled / *2
 0691 MON2 voltage/current output switching
0:Voltage -10~10V output
1:Voltage 0~10V output
2:Current 0~20mA output
1/1 1 Disabled / *2
 0692 MON2 output gradient characteristic
0:Negative inclination (downward slope)
1:Positive inclination (upward slope)
1/1 1 Enabled / *2
 0693 MON2 bias adjustment -10.0~100.0% 0.1/0.1 0.0 Enabled / *2
This parameter moves to a fundamental parameter.
*1: For the adjustment range, see the table on page K-35.
*2: For details, refer to Instruction Manual (E6581341) specified in Section 6.36.
