[27] Communication function [1/5] Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Constant Reference
 0784 Data1 0~255 1/1 0 *1 ●/● ● ● *2
 0785 Data2 0~255 1/1 0 *1 ●/● ● ● *2
 0786 Data3 0~255 1/1 0 *1 ●/● ● ● *2
 0787 Data4 0~255 1/1 0 *1 ●/● ● ● *2
 0788 Data5 0~255 1/1 0 *1 ●/● ● ● *2
 0789
MAC address
Data6 0~255 1/1 0 *1 ●/● ● ● *2
 0792 Data1 0000~FFFF 1/1 0 *1 ●/● ● ● *2
 0793 Data2 0000~ FFFF 1/1 0 *1 ●/● ● ● *2
 0794 Data3 0000~ FFFF 1/1 0 *1 ●/● ● ● *2
 0795 Data4 0000~ FFFF 1/1 0 *1 ●/● ● ● *2
 0796 Data5 0000~ FFFF 1/1 0 *1 ●/● ● ● *2
 0797 Data6 0000~ FFFF 1/1 0 *1 ●/● ● ● *2
 0798 Data7 0000~ FFFF 1/1 0 *1 ●/● ● ● *2
 0799
Device name
Data8 0000~ FFFF 1/1 0 *1 ●/● ● ● *2
 0800 Communication speed (2-wire RS485)
0:9600 bps
1:19200 bps
2:38400 bps
1/1 1 Enabled ●/● ● ● 6. 34. 1
 0801
Parity (common to 2-wire RS485 and
4-wire RS485)
0:Non parity
1:Even parity
2:Odd parity
1/1 1 Enabled ●/● ● ● 6. 34. 1
 0802 Inverter number (common) 0~247 1/1 0 Enabled ●/● ● ● 6. 34. 1
 0803
Communications time-out time (common to
2-wire RS485 and 4-wire RS485)
0:OFF, 1~100 sec. 1/1 0 Enabled ●/● ● ● 6. 34. 1
 0804
Communications time-out action (common
to 2-wire RS485 and 4-wire RS485)
0~8 1/1 8 Enabled ●/● ● ● 6. 34. 1
 0805 Send waiting time (2-wire RS485) 0.00:Default, 0.01~2.00 sec. 0.01/0.01 0.00 Enabled ●/● ● ● 6. 34. 1
 0806
Master/slave setting for inverter-to-inverter
communications (2-wire RS485)
0:Slave (issues a 0Hz command if something
goes wrong with the master)
1:Slave (continues operation if something goes
wrong with the master)
2:Slave (trips for emergency stop if something
goes wrong with the master)
3:Master (sends a frequency command)
4:Master (sends an output frequency)
5. -
6. -
1/1 0 Enabled ●/● ● ● 6. 34. 1
 0807 Protocol selection (2-wire RS485)
0:TOSHIBA
1:MODBUS
1/1 0 Enabled ●/● ● ● 6. 34. 1
*1: This parameter is read only.
*2:This function is for Etherenet communication option (planning).
