Toshiba TOSVERT VF-PS1 User Manual

K-26
E6581386
11
[27] Communication function [2/5] Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Constant Reference
 0808
Communication1 time-out condition
selection
0:Disconnection detection
1:When communication mode enable
2:1+Driving operation
1/1 0 Enabled ●/● ● ● *1
 0810 Frequency point selection
0:Disabled
1:2-wire RS485
2:4-wire RS485
3:Communication add option
1/1 0 Enabled ●/● ● ● 6. 34. 1
 0811 Point 1 setting 0-100% 1/1 0 Enabled *2 ●/● ● ● 6. 34. 1
 0812 Point 1 frequency 0.0~ Hz 0.1/0.01 0.0 Enabled *2 ●/● ● ● 6. 34. 1
 0813 Point 2 setting 0~100% 1/1 100 Enabled *2 ●/● ● ● 6. 34. 1
 0814 Point 2 frequency 0.0~ Hz 0.1/0.01 *6 Enabled *2 ●/● ● ● 6. 34. 1
 0815
Address monitor
(Modbus puls)
1~64 1/1 1 *5 ●/● ● ● *3
 0816
Command selection
(Modbus puls)
0: Prohibit
1: Permit
1/1 0 Enabled ●/● ● ● *3
 0817
Number of command
(Modbus puls)
0~8 1/1 0 Enabled ●/● ● ● *3
 0818
Number of monitors
(Modbus puls)
0~8 1/1 0 Enabled ●/● ● ● *3
 0819
Command station
(Modbus puls)
0~64 1/1 0 Enabled ●/● ● ● *3
 0820 Communication speed (4-wire RS485)
0:9600 bps
1:19200 bps
2:38400 bps
1/1 1 Enabled ●/● ● ● 6. 34. 1
 0821
Baud rate
(Ethernet)
0:Automatic detection
1:10Mbps Full
2:10Mbps Half
3:100Mbps Full
4:100Mbps Half
1/1 0 Enabled ●/● ● ● *4
 0822
Baud rate monitor right port
(Ethernet)
0:Automatic detection
1:10Mbps Full
2:10Mbps Half
3:100Mbps Full
4:100Mbps Half
1/1 - *5 ●/● ● ● *4
 0823
Baud rate monitor left port
(Ethernet)
0:Automatic detection
1:10 Mbps Full
2:10Mbps Half
3:100Mbps Full
4:100Mbps Half
1/1 - *5 ●/● ● ● *4
 0824 (Reservation)
0:-
1:-
2:-
3:-
1/1 0 Enabled ●/● ● ● *4
*1:  For details, refer to Instruction Manual (E6581413) specified in Section 6.36. *2: Effective when a command value is sent by communication.
*3:  This function is for Modbus plus communication option (planning). *4: This function is for Etherenet communication option (planning).
*5: This parameter is read only. *6: Inverter with a model number ending with -WN1: 60.0 -WP1: 50.0
