[27] Communication function [4/5] Sensorless vector/PG feedback control (●:Effective, -:Ineffective)
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Vector
control
PM
control
V/f Constant Reference
 0853
Communication option station address
monitor
0~255 1/1 0 Enabled ●/● ● ● *1
 0854
Communication option speed switch
monitor
DeviceNet/CC-Link
0~255 1/1 0 Enabled ●/● ● ● *1

0856 Number of motor poles for communication
1:2 poles
2:4 poles
3:6 poles
4:8 poles
5:10 poles
6:12 poles
7:14 poles
8:16 poles
1/1 2 Enabled ●/● ● ● *1
 0870 Block write data 1
0:Disabled
1:Command information 1
2:Command information 2
3:Frequency command
4:Terminal board output data
5:Communication analog data
6:Rotational speed command
1/1 0 Enabled ●/● ● ● 6. 34. 1
 0871 Block write data 2 Ditto 1/1 0 Enabled ●/● ● ● 6. 34. 1
 0875 Block read data 1
0:Deselect
1:Status information
2:Output frequency
3:Output current
4:Output voltage
5:Alarm information
6:PID feedback value
7:Input terminal board monitor
8:Output terminal board monitor
9:VI/II terminal board monitor
10:RR/S4 terminal board monitor
11:RX terminal board monitor
12:Input voltage (DC detection)
13:Speed feedback frequency
14:Torque
15:MY monitor 1
16:MY monitor 2
17:MY monitor 3
18:MY monitor 4
19:Free notes
20:Rotational speed
1/1 0 Enabled ●/● ● ● 6. 34. 1
*1:  For details, refer to Instruction Manual (E6581281, E6581343, E6581477) specified in Section 6.36.
