Toshiba TOSVERT VF-PS1 User Manual

K-35
E6581386
11
[Monitor FM/AM/pulse output function selection (1/3)] Sensorless vector/PG feedback control (●: valid, -: invalid)
FM/AM/pulse output Monitor output
Option No.
Communicati
on No.
Option No.
Communicati
on No.
Function
Unit
(Communicat
ion)
Trip retention
Vector
control
PM control V/f Reference
0 FD00 0 FE00 Output frequency 0.01Hz ○ ●/● ● ●
1 FD02 1 FE02 Frequency command value 0.01Hz
○
●/● ● ●
2 FD03 2 FE03 Output current 0.01%
○
●/● ● ●
3 FD04 3 FE04 Input voltage (DC detection) 0.01%
○
●/● ● ●
4 FD05 4 FE05 Output voltage 0.01%
○
●/● ● ●
5 FD15 5 FE15 Compensated frequency 0.01Hz
○
●/● ● ●
6 FD16 6 FE16 Speed feedback (real-time value) *1 0.01Hz
○
-/● - -
7 FD17 7 FE17 Speed feedback (1-second filter) *1 0.01Hz
○
-/● - -
8 FD18 8 FE18 Torque 0.01%
○
●/● ● ●*2
9 FD19 9 FE19 Torque command 0.01%
○
- - -
11 FD20 11 FE20 Torque current 0.01%
○
●/● - ●*2
12 FD21 12 FE21 Exciting current 0.01%
○
●/● - ●*2
13 FD22 13 FE22 PID feedback value 0.01Hz
○
●/● ● ●
14 FD23 14 FE23 Motor overload factor (OL2 data) 0.01%
○
●/● ● ●
15 FD24 15 FE24 Inverter overload factor (OL1 data) 0.01%
○
●/● ● ●
16 FD25 16 FE25
Regenerative braking resistance
overload factor (OLr data)
1%
○
●/● ● ●
17 FD28 17 FE28 Regenerative braking resistor load factor (% ED) 1%
○
●/● ● ●
18 FD29 18 FE29 Input power 0.01kW
○
●/● ● ●
19 FD30 19 FE30 Output power 0.01kW
○
●/● ● ●
23 FE39 23 FE39 Optional AI2 input 0.01% × ●/● ● ●
24 FE35 24 FE35 RR/S4 input 0.01% × ●/● ● ●
25 FE36 25 FE36 VI/II input 0.01% × ●/● ● ●
26 FE37 26 FE37 RX input 0.01% × ●/● ● ●
27 FE38 27 FE38 Optional AI1 input 0.01% × ●/● ● ●
28 FE40 28 FE40 FM output 0.01 × ●/● ● ●
29 FE41 29 FE41 AM output 0.01 × ●/● ● ●
30 FE51 - - Fixed output 1 0.01% × ●/● ● ●
31 FA51 *3 - - Communication data output 1 × ●/● ● ●
32 FE50 - - Fixed output 2 0.01% × ●/● ● ●
33 FE52 - - Fixed output 3 0.01% × ●/● ● ●
- - 31 FA65 Communication data output 0.01% × ●/● ● ●
- - 32 FE66
Attached to expansion I/O card 1 CPU
version
- × ●/● ● ●
5.16
8.3
*1: Estimated speed is output if there is no PG feedback. If used as pulse input command with PG feedback option, frequency is displayed as in the PG feedback.
*2: Reference data
*3: Communication no. FA51 is used for FM, FA52 for AM, FA53 for MON1 and FA54 for MON2 and pulse output, respectively.
 For details, refer to Section 5.16; [Terminal FM-related parameters].
 For monitor indications, refer to Section 8.3; [Set up values of monitor indication parameters].
