[Monitor FM/AM/pulse output function selection (2/3)] Sensorless vector/PG feedback control (●: valid, -: invalid)
FM/AM/pulse output
Monitor output
Option No.
Communicati
on No.
Option No.
Communicati
on No.
Function
Unit
(Communica
tion)
Trip retention
Vector
control
PM control V/f Reference
- - 33 FE67
Attached to expansion I/O card 2 CPU version
- × ●/● ● ●
34 FE76 34 FE76 Integral input power
Depends on
× ●/● ● ●
35 FE77 35 FE77 Integral output power
Depends on
× ●/● ● ●
45
0006 *3
0671 *4
- - Gain display 1 - ●/● ● ●
46 FE60 - -
My function monitor 1 (Output of
unsigned value)
1 × ●/● ● ●
47 FE61 - -
My function monitor 2 (Output of
unsigned value)
1 × ●/● ● ●
48 FE62 - -
My function monitor 3 (Output of signed
value) *2
1 × ●/● ● ●
49 FE63 - -
My function monitor 4 (Output of signed
value) *2
1 × ●/● ● ●
50 FD00 50 FE00 Signed output frequency *5 0.01Hz
○
●/● ● ●
51 FD02 51 FE02 Signed frequency command value *5 0.01Hz
○
●/● ● ●
52 FD15 52 FE15 Signed compensated frequency *5 0.01Hz
○
●/● ● ●
53 FD16 53 FE16
Signed speed feedback (real-time value)*5
0.01Hz
○
-/● - -
54 FD17 54 FE17
Signed speed feedback (1-second filter) *5
0.01Hz
○
-/● - -
55 FD18 55 FE18 Signed torque *5 0.01%
○
●/● ● ●*1
56 FD19 56 FE19 Signed torque command *5 0.01%
○
- - -
58 FD20 58 FE20 Signed torque current *5 0.01%
○
●/● - ● *1
59 FD22 59 FE22 Signed PID feedback value *5 0.01
○
●/● ● ●
60 FE37 60 FE37 Signed RX input *5 0.01% × ●/● ● ●
61 FE38 61 FE38 Signed optional AI1 input *5 0.01% × ●/● ● ●
62 FE51 - - Signed fixed output 1 - × ●/● ● ●
63 FE50 - - Signed fixed output 2 - × ●/● ● ●
64 FE52 - - Signed fixed output 3 - × ●/● ● ●
5.16
8.3
*1: Reference data *2: An absolute value is output for pulse train output of 48 and 49.
*3: Communication no. for FM output *4: Communication no. for AM output
*5: If a negative value is specified, the negative sign “-” is displayed. When read through by communications device, the negative sign is affixed only FE18~FE20, FE37 and FE38 values.
For details, refer to Section 5.16; [Terminal FM-related parameters]. For monitor indications, refer to Section 8.3; [Set up values of monitor indication parameters].
