3. DISASSEMBLY AND REASSEMBLY
SPAA-214-R1
3.2 DISASSEMBLING THE MAIN BODY
3-13
NOTE: When reassembling, the Cables must be routed in the same manner as before
disassembly as shown in the photo below.
Cable
Cable
Wire Holde
r
Cable Guide
Cable Guide
