Toshiba VF-PS1 - Terminal Function Selection

E6581386
F-6
6
6.3 Terminal function selection
6.3.1 Keeping an input terminal function always active (ON)
 ,  ,  : Always ON function selection 1 ~ 3
• Function
This parameter specifies an input terminal function that is always kept active (ON). (Only one function
selectable)
[Parameter setting]
Title Function Adjustment range Default setting
 Always ON function selection 1 ~ 
 Always ON function selection 2 ~ 
 Always ON function selection 3 ~ 
* The selected function is always kept active regardless of the type of logic (positive or negative) in the table of
function settings in 7.2.1.
6.3.2 Modifying input terminal functions
 : Input terminal function selection 1 (F)
 : Input terminal function selection 2 (R)
 : Input terminal function selection 4 (RES)
 : Input terminal function selection 5 (S1)
 : Input terminal function selection 6 (S2)
 : Input terminal function selection 7 (S3)
 : Input terminal function selection 8 (RR/S4)
 ~  :
Input terminal function selection 9~16
⇒ For details, refer to Section 7.2.1.
• Function
Use the above parameters to send signals from an external programmable controller to various control input
terminals to operate and/or set the inverter.
The desired contact input terminal functions can be selected from about 80 types (-). This gives system
design flexibility.
Using the SW3 switch, the function of the RR/S4 terminal can be selected between analog input and contact
input. By default, the RR/S4 terminal is set as an analog input terminal (voltage input terminal). To use it as a
contact in
p
ut terminal
,
therefore
,
y
ou need to turn the SW3 switch to the S4
p
osition.
Q Setting of contact input terminal function
Terminal
symbol
Title Function Adjustment range
Default
setting
–  Always ON function selection 1  (ST)
– ,  Always ON function selection 2, 3 
F  Input terminal function selection 1 (F)  (F)
R  Input terminal function selection 2 (R)  (R)
RES  Input terminal function selection 4 (RES)  (RES)
S1  Input terminal function selection 5 (S1)  (S1)
S2  Input terminal function selection 6 (S2)  (S2)
S3  Input terminal function selection 7 (S3)
~
(⇒ Refer to
Section 11.)
 (S3)
The terminal below is operative only when SW3 is in the S4 position. – –
RR/S4  Input terminal function selection 7 (S4) ~ [Note 2]  (S4)
Note 1: The function that has been selected using , and  (always ON function selection 1~3
parameter) are always activated.
Note 2: When using the RR/R4 terminal as a contact input terminal (sink logic), always turn the SW3 slide switch to
the S4 position.
