E6581386
F-77
6
Title Function Adjustment range Default setting
Block read data 1
:Deselect
:Status information
:Output frequency
:Output current
:Output voltage
:Alarm information
:PID feedback value
:Input terminal board monitor
:Output terminal board monitor
:VI/II terminal board monitor
:RR/S4 terminal board monitor
:RX terminal board monitor
:Input voltage (DC detection)
:Speed feedback frequency
:Torque
:MY monitor 1
:MY monitor 2
:MY monitor 3
:MY monitor 4
:Free notes
:Rotational speed
Block read data 2 Ditto
Block read data 3 Ditto
Block read data 4 Ditto
Block read data 5 Ditto
Free notes ~
* : No action .... No action is taken even if a timeout occurs.
Alarm ......... An alarm goes off if a timeout occurs.
The message “” blinks at the left end of the operation panel.
Trip ............. The inverter trips when a communication time-over occurs.
The message “” blinks on the operation panel.
Note:Changes to the parameters , and do not take effect until the power is turned off and
then on again.
6.34.2 Open network option
~ : Communication option settings 1 to 7
~ : Communication option settings 8 to 13
: Disconnection detection extended time
: Inverter operation at disconnection
: Preset speed operation selection
, : Selection of monitoring
: Number of motor poles for communication
⇒ For details, refer to Instruction Manual (E6581281, E6581343) specified in Section 6.36.
6.35 My function
: Input function target 11~ : My function selection
⇒ For details, refer to Instruction Manual (E6581335) specified in Section 6.36.
