E6581386
H-6
8
8.3 Changing status monitor function
Q Changing the display format while power is on
The item displayed in the standard monitor mode (*1 on the left side of table on page H-2), for example, operation
frequency which is displayed by default in this way: “=” when power is on or “” when power is off, can be
changed to any item shown on page H-7. This new format, however, will not display an assigned prefix such as or
.
・Standard monitor mode ⇒ Standard monitor display selection ()
Title Function Adjustment range Default setting
Standard monitor hold
function
:Real time
:Peak hold
:Minimum hold
Standard monitor
display selection
~
⇒ Refer to page H-7.
Specify how to output the monitored values that are assigned to status monitors 1 through 4.
If is set to , the monitored values selected with (standard monitor display selection parameter) are
displayed one after another.
For peak hold values and minimum hold values, the minimum values in each operation mode are displayed. When the
motor is at a standstill, the values monitored last are held as they were until the motor is started the next time.
The maximum and minimum values monitored after power is turned on or after the reset with the EASY key are always
displayed no matter whether the motor is in operation or at a standstill.
Q Changing contents of status monitor indication
Regarding contents of status monitor indications appearing in the left column of the table on page H-2, those marked
with *2 to *5 can be changed for others. Select a desirable monitor function from among optional monitor functions
appearing on page H-7.
*2 Frequency command
⇒ Changeable by status monitor 1 display selection ().
*3 Output current
⇒ Changeable by status monitor 2 display selection ().
*4 Input voltage
⇒ Changeable by status monitor 3 display selection ().
*5 Output voltage
⇒ Changeable by status monitor 4 display selection ().
Title Function Adjustment range Default setting
Status monitor 1 display selection ~ ⇒ Refer to page H-7.
Status monitor 2 display selection Ditto
Status monitor 3 display selection Ditto
Status monitor 4 display selection Ditto
*If to are set at “” (Output frequency) the operation frequency is not held in trip status.
