Title Function Adjustment range Example of setting
 Commercial power/inverter switching output selection ~ or 
 Commercial power/inverter switching frequency ~Hz Power supply frequency etc.
 Inverter-side switching waiting time ~ sec.
According to model
⇒ Refer to page K-41.
 Commercial power-side switching waiting time ~ sec. 
 Commercial power switching frequency holding time ~ sec. 
 Input terminal function selection 7 (S3) ~

(Commercial power switching)
 Output terminal function selection 1 (OUT1) ~ 

(Commercial power/inverter
switching output 1)
 Output terminal function selection 2 (OUT2) ~ 

(Commercial power/inverter
switching output 2)
- Warning -
• When switching to commercial power, make sure that the direction in which the motor rotates when operated
on commercial power agrees with the forward direction when operated via the inverter.
• Do not select any option (=) of  (reverse rotation prohibition selection) that prohibits forward
rotation. Or it becomes impossible to switch to commercial power, because the motor cannot rotate in the
forward direction.
