[Output terminal function setting 3/3] Sensorless vector/vector with sensor (●: valid, -: invalid)
Positive
lo
g
ic
Ne
g
ative
lo
g
ic
Function Vecto
r
control PM control V/f Reference
238 239 My function output 9
●/●
●●
240 241 My function output 10
●/●
●●
242 243 My function output 11
●/●
●●
244 245 My function output 12
●/●
●●
246 247 My function output 13
●/●
●●
248 249 My function output 14
●/●
●●
250 251 My function output 15
●/●
●●
252 253 My function output 16
●/●
●●
254 255 Always OFF (for terminal signal tests)
●/●
●●
