103
1
Before driv
ing
PRIUS +_OM_OM4782
1E_(EE)
1-4.
Adjustable components (seats, mirrors, steering wheel)
F
r
ont seats
Seat position adjustment
lever
Seatback angle adjustment
lever
V
ertical height adjustment
lever (for driver
’s side)
*
Lumbar support adjustment
switch (for driver
’s side)
*
*
: If equipped
