4-3. Do-it-yourself maintenance
4
Maintenance and
care
PRIUS +_OM_OM4782
1E_(EE)
Engine compar
tment
12-volt battery
P
. 413
Engine coolant reservoir
(
P
. 408)
Engine oil level dipstick
(
P
. 404)
Engine oil filler cap
(
P
. 405)
Power control unit coolant
reservoir
(
P
. 408)
Fuse box
(
P
. 433)
Radiat
or (
P
. 410)
Condenser
(
P
. 410)
Electric cooling fans
W
asher fluid
tank
(
P.
4
1
1
)
402
404
