266
2-3. Operating the lights and windshield wipe
rs
PRIUS +_OM_OM4782
1E_(EE)
F
og light switc
h
The fog lights secure excellent visibility in difficult driving condi-
tions, such as in rain and f
og.
Front and rear fog light switch (if equipped)
T
urns the front and
rear fog
lights off
T
urns the front fog lights on
T
urns both front and rear
fog lights on
Releasing the switch returns
the ring to the
position.
Operating the switch ring again
turns only the rear fog light off.
265
267
