330
3-1. Using the air cond
itioning system
and defogger
PRIUS +_OM_OM4782
1E_(EE)
Adjusting the temperature set
ting
Slide
to the left or
right to select the temperature set-
ting display (
).
T
urn
to the clockwise to
raise the temperature
, or
counterclock
wise to lower
.
Changing the air outlet
s
Slide
to the left to select the air outlet display
()
.
T
urn
clockwise or counterclockwise.
The air flow shown on the display indicates the following:
Air flows to the upper body
.
STEP
1
STEP
2
STEP
1
STEP
2
329
331
