447
4-3. Do-it-your
self maintenance
4
Maintenance and
care
PRIUS +_OM_OM4782
1E_(EE)
Replacing light bulbs
Headlight
low beams (halogen headlight
s)
T
u
rn the bulb base counterclock-
wise.
Unplug the connector while
pressing the lock release.
Replace the light bulb, and install
the bulb base.
Align the 3 tabs on the light bulb
with the mounting, and insert.
STEP
1
STEP
2
STEP
3
