216
2-1. Driving procedures
PRIUS +_OM_OM4782
1E_(EE)
Changing “POWER” switch modes
Modes can be changed by p
ressing the “POWER” switch with the
brake pedal released. (Th
e mode
changes each time the switch is
pressed.)
Off
The emergency flashers can
be used.
ACCESSOR
Y mode
Some electrical components
such as the audio system can
be used.
The “POWER” switch indicator
turns amber
.
ON mode
All electrical components can
be used.
The “POWER” switch indicator
turns amber
.
