117
1
1-4. Adjustable components (seats, mirro
rs, steering wheel)
Before driv
ing
PRIUS +_OM_OM4782
1E_(EE)
Head r
estraints
Head restraint
s are provided for all seat
s.
Front and second seat
s
Up
Pull the head restraints up.
Down
Press and hold the lock
release button when lowering
the head restraint.
Third seat
s
Up
Pull the head restraints up.
Down
Press and hold the lock
release button when lowering
the head restraint.
Lock release button
Lock release button
116
118
