107
1
1-4. Adjustable components (seats, mirro
rs, steering wheel)
Before driv
ing
PRIUS +_OM_OM4782
1E_(EE)
Second seats
Moving a second seat fo
r third seat access
Pull up the lever (e
ither
or
), tilt the se
atback for
ward,
and slide the seat forward.
After getting in or out of the
vehi-
cle, slide the seat backward and
raise the seatback.
Gently rock the seat back and
forth to ensure that it is securely
locked.
Seatback angle adjustment
lever
Seat position adjustment
lever
106
108
