411
4-3. Do-it-your
self maintenance
4
Maintenance and
care
PRIUS +_OM_OM4782
1E_(EE)
W
asher fluid
Open the lid
.
Check the was
her fluid leve
l on
the level gauge.
“NORMAL”
“LOW”
If the washer fluid level is at
“LOW”, add washer fluid.
STEP
1
STEP
2
STEP
3
410
412
