482
5-2. Steps to take in an
emergency
PRIUS +_OM_OM4782
1E_(EE)
If y
ou hav
e a flat tire (v
ehic
les with spare tir
e)
Remove the flat tire and replace it
with the sp
are tire provided.
Before jacking up the vehicle
S
top the vehicle on a hard, flat surface.
Set the parking brake.
Shift the shift posit
ion to P
.
S
top the hybrid system.
Turn on the emergency flashers.
Location of the spare tire, jack and tools
Center deck
board
Jack
Sp
a
r
e
t
ir
e
Jack handle
T
owing eyelet
Wheel nut
wrench
Left si
de
deck board
Center auxiliary
box
481
483
