327
3-1. Using the air cond
itioning system
and defogger
3
Interior features
PRIUS +_OM_OM4782
1E_(EE)
Switching functions and changing settings
Slide
left and right to
select the function.
The function currently being set
up will be surrounded by a frame.
The arrows displayed at the sides
of the frame indicate the direc-
tions in which the frame can be
moved.
Fan speed
T
emp
erature setting
Air outlet
T
urn
to adjust
/select the setting.
STEP
1
STEP
2
326
328
