121
1-4. Adjustable components
(s
eats, mirrors, steering wheel)
1
Before driv
ing
PRIUS +_OM_OM4782
1E_(EE)
Fastening the sea
t belt (second center seat)
Press the plate to release, and
pull out the seat belt.
Connect by inserting plate B
into buckle B until a click
sound is heard.
Secure the belt by inserting
plate A into buckle A until a
click sound is heard.
STEP
1
STEP
2
Plate B
Buckle B
STEP
3
Plate A
Buckle A
