430
4-3. Do-it-yourself maintenance
PRIUS +_OM_OM4782
1E_(EE)
Electr
onic k
ey batter
y
Replace the battery with a new one if it is depleted.
Y
ou will need the following items:
Flathead screwdriver
Lithium b
attery CR1632
Replacing the battery
T
ake o
ut the mechanical key
.
Remove the c
over
.
T
o prevent damage, cover the
tip of the screwdriver with a
rag.
STEP
1
STEP
2
429
431
