4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS +_OM_OM47821E_(EE)
FUSE Ampere Circuit
30 MIR HTR 10A Outside rear view mirror defoggers
31 RAD NO.1 15A Audio system, navigation system
32 DOME 10A
Door courtesy lights, personal
lights, interior lights, front foot
lights, vanity lights, inside rear
view mirror, overhead console
33 ECU-B 7.5A
Smart entry & start system, multi-
plex communication system, per-
sonal lights, gauges and meters
34 H-LP LH HI 10A Left-hand headlight (high beam)
35 H-LP RH HI 10A Right-hand headlight (high beam)
36 EFI NO.2 10A
Multiport fuel injection system/
sequential multiport fuel injection
system
37 IGCT NO.3 10A Cooling system
38 SPARE 30A Spare fuse
39 SPARE 10A Spare fuse
40 SPARE 7.5A Spare fuse
41 EFI MAIN 20A
Multiport fuel injection system/
sequential multiport fuel injection
system, EFI NO.2
42 BATT FAN 10A Battery cooling fan
43 IG2 20A
Multiport fuel injection system/
sequential multiport fuel injection
system, MET-IGN, IGN, hybrid
system
