4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS +_OM_OM47821E_(EE)
FUSE Ampere Circuit
14 STOP 10A
Stop lights, high mounted stop-
light, brake system, driver support
system
15 P FR DOOR 25A Power windows
16 D FR DOOR 25A Power windows
17 DOOR RR 25A Power windows
18 DOOR RL 25A Power windows
19 S/ROOF 30A Panoramic roof shades
20 ECU-IG NO.1 10A
Electric cooling fans, multiplex
communication system
21 ECU-IG NO.2 10A
Driver support system, Pre-crash
safety System, inside rear view
mirror, yaw rate & G sensor, brake
system, electric power steering,
navigation system, panoramic roof
shades, seat belt pretensioners,
audio system, emergency flash-
ers, turn signal lights, windshield
wipers, headlight cleaner
22 GAUGE 10A
Headlight leveling system, seat
belt reminder light, gauges and
meters
23 A/C 10A Air conditioning system
24 WASHER 15A Windshield washer
25 RR WIP 20A Rear window wiper and washer
