6-1. Specifications
6
Vehicle specifications
PRIUS +_OM_OM47821E_(EE)
Electric motor (Traction motor)
Hybrid battery (traction battery)
Lubrication system
*: The engine oil capacity is a reference quantity to be used when changing the
engine oil. Warm up the engine and turn off the hybrid system, wait more
than 5 minutes, and check the oil level on the dipstick.
Type Permanent magnet motor
Maximum output 60 kW
Maximum torque 207 N•m (21.1 kgf•m, 153 ft•lbf)
Type Lithium-ion battery
Voltage 3.6 V/cell
Capacity 5 Ah
Quantity 56 cells
Overall voltage 201.6
Oil capacity
(Drain and refill
reference
*)
With filter
Without filter
4.2 L (4.4 qt., 3.7 Imp.qt.)
3.9 L (4.1 qt., 3.4 Imp.qt.)
