Ar che r D9
AC1900 Wireless Dual Band Gigabit ADSL2+ Modem Router User Guide
 Auth entication Type : This option should be chosen if the key type is WEP(ASCII) or
WEP(HEX). It indicates the authorization type of the Root AP.
 Password
: If the AP your modem router is going to connect needs password, you need to fill
the password in this blank.
Click Sav e to save your settings.
4.8.2 WPS Settings
This section will guide you to add a new wireless device to an existing network quickly by WPS
(also called QSS) function.
a). Choose menu “WPS Settings”, and you will see the next screen (shown in Figure 4-32).
Figure 4-32
 WPS: Enable or disable the WPS function here.
 Current PIN: The current value of the modem router's PIN is displayed here.
 Restore PIN: Restore the PIN of the modem router to its default.
 Generate New PIN: Click this button to get a new random PIN code. You can ensure the
network security by generating a new PIN.
 Add dev ice : You can add a new device to the existing network manually by clicking this
button.
b). To add a new device:
If the wireless adapter supports Wi-Fi Protected Setup (WPS), you can establish a wireless
connection between wireless adapter and modem router using either Push Button Configuration
(PBC) method or PIN method.

Note:
To build a successful connection by WPS, you should also do the corresponding configuration of
the new device for WPS function meanwhile.
I. Use the Wi-Fi Protected Setup Button
Use this method if your client device has a Wi-Fi Protected Setup button.
Step 1: Press the WPS button on the side of the modem router, as shown in the following figure.
44
