TP-Link Easy Smart Switch User Manual

Switching Configuring IGMP Snooping
User Guide 27
3
Configuring IGMP Snooping
Choose the menu Switching > IGMP Snooping to load the following page.
Figure 3-1 Configuring IGMP Snooping
Follow these steps to configure IGMP Snooping.
1) Enable IGMP Snooping. Enable or disable report message suppression according to
your needs. Click Apply.
IGMP Snooping Enable or disable IGMP Snooping globally.
Report Message
Suppression
Enable or disable Report Message Suppression globally. When enabled, the
switch will only forward the first IGMP report message for each multicast group to
the IGMP querier during one query interval, and suppress subsequent IGMP report
messages for the same multicast group. This feature prevents duplicate report
messages from being sent to the IGMP querier.
2) In the table below, you can view the current IGMP group information.
IP Address Displays the IP address of the multicast group.
VLAN ID Displays the VLAN ID of the multicast group. All port members of a multicast
group should be included in the same VLAN.
Ports Displays the forwarding port list of the multicast group.

TP-Link Easy Smart Switch Specifications

General

Cable Diagnostics	Yes
Power Input	100-240VAC, 50/60Hz
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Model	Easy Smart Switch
Port Type	RJ45
Speed	10/100/1000Mbps
MAC Address Table	8K
Jumbo Frame	9KB
QoS	4 queues per port, priority-based QoS
IGMP Snooping	V1/V2/V3 Snooping
Port Mirroring	Yes
Management	Web-based GUI
Standards and Protocols	IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, IEEE 802.1Q
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
