TP-Link Easy Smart Switch User Manual

User Guide 48
Configuring VLAN Configuring MTU VLAN
2
Configuring MTU VLAN
Choose the menu VLAN > MTU VLAN to load the following page.
Figure 2-1 Configuring MTU VLAN
Follow these steps to configure MTU VLAN:
1) Select MTU VLAN configuration as Enable. Click Apply.
MTU VLAN
Configuration
Enable or disable the MTU VLAN mode.
2) In the table below, change the uplink port from the drop-down list according to your
needs. Click Apply.
Change Uplink
Port
Select the desired uplink port from the drop-down list. The uplink port will
build up several VLANs with each of the other ports.

TP-Link Easy Smart Switch Specifications

General

Cable Diagnostics	Yes
Power Input	100-240VAC, 50/60Hz
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Model	Easy Smart Switch
Port Type	RJ45
Speed	10/100/1000Mbps
MAC Address Table	8K
Jumbo Frame	9KB
QoS	4 queues per port, priority-based QoS
IGMP Snooping	V1/V2/V3 Snooping
Port Mirroring	Yes
Management	Web-based GUI
Standards and Protocols	IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, IEEE 802.1Q
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
