Configuring VLAN Overview
User Guide 47
switch will first insert a VLAN tag to the frame, using the PVID (Port VLAN ID) of the port as
its VID, and then forward it as a tagged frame.
Note:
● The switch works in one and only one VLAN mode at any time. When a specific VLAN mode
is enabled, the other two VLAN modes will be disabled automatically and the corresponding
VLAN configuration will be lost.
● The switch supports up to 32 VLANs simultaneously.
