User Guide 78
Configuring PoE (Only for Certain Devices) Configuring PoE Auto Recovery
2) In the Port Config section, select the desired ports and specify the parameters . Click
Apply.
Ping IP Address Enter the IP address of the PD connected to the port.
Ping IP Address should be the same as the connected PD’s IP address.
Otherwise, the switch will continually reboot the PD.
Startup Delay Specify how long the switch waits for the connected PD’s rebooting before the
switch starts to ping the PD’s IP address.
Interval Specify the interval between two consecutive ping packets.
Failure Threshold Specify the threshold for ping failures.
If the switch fails to get the ping response from the PD on the port, the switch
will retry until the number of ping failures reaches the threshold, then the switch
reboots the PD.
Break Time Specify how soon the switch reboots the PD after the number of ping failures
reaches the threshold.
Failures Display the number of ping failures since the latest reboot of the PD. It will be
reset when the PD responds to the ping packet or is rebooted.
Reboots Display the number of PD’s reboots. It will be reset after reaching 9,999 or
when the switch is rebooted.
Total Pings Display the total number of ping packets that the switch sends to the
connected PD. It will be reset after reaching 9,999 or when the switch is
rebooted.
Status Enable or disable PoE Auto Recovery on the desired ports. To make it enabled,
enable PoE Auto Recovery both globally and on the port.
