4 Installation / Preparation for commissioning
4.1 Connection – notes
Mainly, the electrical characteristics are defined by the variable connection technique.
Whether the measuring system supports
additional interfaces, e.g. a SSI interface
external inputs such as the Preset
is therefore defined by the device specific pin assignment.
The connection can be made only in connection with the device specific pin
assignment!
At the delivery of the measuring system one device specific pin assignment in printed
form is enclosed. The number of the pin assignment is also noted on the nameplate
of the measuring system.
