7.2.1.1 Station status 1
Standard diagnosis byte 1
bit 7
Master_Lock
Slave has been parameterized
from another master (bit is set by
the master)
bit 6
Parameter_Fault
The parameter telegram last sent
has been rejected by the slave
bit 5
Invalid_Slave_Response
Is set by the master, if the slave
does not respond
bit 4
Not_Supported
Slave does not support the
requested functions.
bit 3
Ext_Diag
Bit = 1 means an extended
diagnosis report from the slave is
waiting
bit 2
Slave_Cfg_Chk_Fault
The configuration identifier(s)
sent from the master has (have)
been rejected by the slave
bit 1
Station_Not_Ready
Slave is not ready to exchange
cyclical data
bit 0
Station_Non_Existent
The slave has been projected,
but is not available on the bus
7.2.1.2 Station status 2
Standard diagnosis byte 2
bit 7
Deactivated
Slave was removed from the poll
list from the master
bit 6
Reserved
bit 5
Sync_Mode
Is set by the slave after receipt of
the SYNC command
bit 4
Freeze_Mode
Is set by the slave after receipt of
the FREEZE command
bit 3
WD_On
The response monitoring of the
slave is activated
bit 2
Slave_Status
Always set for slaves
bit 1
Stat_Diag
Static diagnosis
bit 0
Prm_Req
The slave sets this bit if it has to
be re-parameterized and
reconfigured.
7.2.1.3 Station status 3
Standard diagnosis byte 3
bit 7
Ext_Diag_Overflow
Overrun for extended diagnosis
bit 6-0
Reserved
